NJ30HW-2415D
NJ30HW-2415D
Output Voltage
15 V
Wattage
30 W
Series
NJ30HW
Channels
Dual
±15V Dual Output 30W High-Isolation DC/DC Converter
9-36V Input, Regulated 4:1 Ultra-Wide Input.
5000 VAC Reinforced Isolation for 250Vrms Working Voltage.
2"x1" Package, Encapsulated UL94V-0 Case.
Adjustable Output Voltage.
Remote On/Off Control.
Efficiency up to 89%.
-40 ~ +100°C Operating.
Protections: Short-Circuit / Over-Current / Over-Voltage / Over-Temperature / Under-Voltage Lockout.
5000 VAC Reinforced Isolation for 250Vrms Working Voltage.
2"x1" Package, Encapsulated UL94V-0 Case.
Adjustable Output Voltage.
Remote On/Off Control.
Efficiency up to 89%.
-40 ~ +100°C Operating.
Protections: Short-Circuit / Over-Current / Over-Voltage / Over-Temperature / Under-Voltage Lockout.
(0.23MB)
or call +44-(0)1785-503110 · email sales@rlpower.co.uk for pricing and availability.
