ISRM20-24

24V Output DIN Rail ORing / Redundancy Diode Module (DC-UPS Function)

20A / 19-29V Input rated output. · ORing / redundancy diode module for running two power supplies as a redundant pair.
Combines two independent supplies into a single protected output for 1+1 or N+1 redundant systems.
Isolating diodes block back-feed between the two inputs, so a fault or short on one supply cannot drag down or feed back into the other.
Also prevents back-feed from a battery or from the load into the power supply.
Two isolated input channels; total output current up to 20A (each channel up to 10A).
Low forward voltage drop of only 0.25V (Vin minus Vout).
LED indicators for DC Power On and DC Low.
Cooling by free air convection, no fan.
Mounts on DIN rail TS35/7.5 or TS35/15.
Protections: Short-Circuit / Overload / Over-Voltage / Over-Temperature.
Input under-voltage and over-voltage alarm.
Operating temperature -40 to +80℃ (refer to derating curve).
Dimensions: 36 x 95.3 x 108mm (W x H x D).
CE, UKCA, UL508, UL/EN 62368-1, TUV, EAC (TP TC 004), RCM and SAA approved.
3 Year Product Warranty.
